W&P 635-50-2-00 Pin Strip 50 Pins 2 Rows 2 mm Spacing 1 piece

Image Representative of Range

W&P 635-50-2-00 Pin Strip 50 Pins 2 Rows 2 mm Spacing 1 piece

W & P Products
Order Code:

10-9612

Brand: W & P Products MPN: 635-50-2-00 EAN-13: 2050001140753
Qty Unit Price (Ex VAT)
3+ £1.59
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
268 available to back orderBack-order availability date - 10/01/2026

W & P Products offers the 635-50-2-00 pin strip with a contact spacing of 2 mm, a total of 50 pins, and two rows. This pin strip is suitable for compact electronic connections where precise spacing is essential. Typical applications include use in circuit boards for consumer electronics and industrial equipment.
Type Pin strip
Number of Positions 50
Number of Rows 2
Case Material Thermoplastic material
Colour Black
Connection Print
Connector Type Pin strip, right angle
Contact Material Copper alloy
Contact surface Gold plated
Cross Section 2mm
Dimensions (L x W x H) 8.5 x 57.2 x 8.5 mm
Height 8.5mm
Insulation Material Thermoplastic material
Insulation Resistance 5 x 108Ω
Length 8.5mm
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute 2 Angled
Nominal Current 1A
Nominal Voltage 250V AC
Pins per row 25
Temperature Range -40 - +105°C
Width 57.2mm
