W & P 141-20-10-60 - Pin Connector - 2.54mm - 20 Pins - 2 Rows

Image Representative of Range

W & P 141-20-10-60 - Pin Connector - 2.54mm - 20 Pins - 2 Rows

W & P Products
Order Code:

10-9540

Brand: W & P Products MPN: 141-20-10-60 EAN-13: 2050001143204
Qty Unit Price (Ex VAT)
10+ £0.557
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
139 available to back orderBack-order availability date - 10/01/2026

The W & P Products 141-20-10-60 pin connector features a contact spacing of 2.54 mm and consists of 20 pins arranged in 2 rows. This connector is ideal for applications requiring reliable electrical connections, such as in circuit board assemblies. W & P Products ensures high-quality manufacturing, catering to the needs of various electronic projects.
Type Pin connector
Number of Positions 20
Number of Rows 2
Board contact surface Gold plated
Case Material Thermoplastic material
Colour Black
Connection Cut & Clip
Connector contact surface Gold plated
Connector Type Power strip
Contact Material Copper alloy
Cross Section 2.54mm
Dimensions (L x W x H) 6 x 30 x 13.55 mm
Height 13.55mm
Insulation Material Thermoplastic material
Insulation Resistance
> 109Ω
Length 6mm
Max. temperature +105°C
Min. temperature -40°C
Misc Attribute 2 Straight
Nominal Current 3A
Nominal Voltage 250V AC
Pins per row 10
Temperature Range -40 - +105°C
Width 30mm
