TruComponents 782636 Pushbutton ,Panel Mount,Off/On,NO/NC,Solder,IP65

TruComponents manufactures the TC-7494500 pushbutton, a tamper-proof panel mount type. Featuring an Off/On latch, it is rated at 250 V AC and 3 A, with IP65 protection suitable for harsh environments. Typical applications include industrial control panels, where its NO/NC configuration and blue illumination provide clear and reliable operation.

Type	Pushbutton
Contact Configuration	SPDT NO/NC
Switch Function	On/Off
Mounting	Panel
Illumination	Blue
Panel Cutout Dimensions	22
Connection	External contact
Dim	(L x W x H) 48.1 x 40 x 46 mm
Factory colour	Red
Front panel cut-out	22.5mm
Height	46mm
IP Rating	IP52
Length	48.1mm
Misc Attribute	S2ER-E3R
Recess Diameter	22mm
Unlocking mechanism	Turn
Weight	22.5g
Width	40mm
