Texas Instruments SN74AC14D Logic IC hex inverter high-speed CMOS technology

Texas Instruments SN74AC14D, also referred to as 2994188, is a logic IC hex inverter designed with high-speed CMOS technology. The device is characterised by its ability to perform the inversion of digital signals with excellent noise immunity and low power consumption, thanks to its advanced CMOS architecture. Integrating six independent inverters into a single 14-pin SOIC package, it offers efficient signal processing capabilities for engineers requiring reliable logic inverters in their circuit designs. Common engineering applications for the SN74AC14D include use in signal conditioning, waveform shaping, and general logic operations where fast switching response and low power dissipation are crucial. Its robust operational parameters make it ideally suited for digital electronics projects and embedded systems where precise logic transformations are necessary.

Logic IC Base Number	SN74AC14
Logic IC Function	Hex Schmitt Inverter
Operating Temperature Range	-40 to +85°C
Package/Case	SOIC (D)
Mounting Type	PCB mount
Operating temperature (max.)	85°C
Operating temperature (min.)	-40°C
Type	Logic IC - Gate and inverter
