TE Connectivity 4-643813-2 MTA-100 SIL Socket 12 Pins Standard

The SIL socket (standard) by TE Connectivity, model 4-643813-2, features a total of 12 pins and falls under the MTA-100 series. It is primarily used in electronic applications for connecting wires to a printed circuit board (PCB) without the need for soldering, enhancing convenience and reliability. This component is suitable for low-voltage, low-current applications, commonly found in home appliances and consumer electronics.

Pitch	2.54mm
No. of Rows	1
No. of Ways	12
Approvals	CSA
AWG (min.)	22
AWG max.	22
Backwall/Post Interruptions	No (Without)
Board contact surface	Tin plated
Body Material	Nylon
Case Material	Polyamide
Circuit Application	Signal
Color	Red
Compatible With Agency/Standards Products	CSA
Compatible With Approved Standards Products	UL E28476
Connection	Cut & Clip
Connector & Contact Terminates To	Wire & Cable
Connector & Housing Type	Receptacle
Connector contact surface	Tin plated
Connector Height	.52
Connector Length	1.2
Connector Mounting Type	Cable Mount (Free-Hanging)
Connector Product Type	Connector Assembly
Connector System	wire-to-wire
Connector Type	Socket, right angle
Connector Width	.275
Contact Current Rating	5a
Contact Current Rating (Max)	5
Contact Finish	Copper alloy
Contact Gender	Female
Contact Material	Copper Alloy
Contact Mating Area Plating Material	Tin (Sn)
Contact Plating	Tin, Matte
Contact Retention	Yes (With)
Contact Retention Within Housing	With
Contact Type	Receptacle
Contact Underplating Material	Nickel
Contacts Preloaded	Yes
Current Rating	5a
Depth	6.99mm
Dim	(L x W x H) 6.99 x 30.48 x 13.21 mm
ELV	Compliant
Factory colour	Red
Flammability Rating	UL94 V-2
Gender	Receptacle
Height	13.21mm
Housing Color	White
Housing Material	Nylon
Industrial packaging	No
Insulation Diameter	1.52mm
Insulation Material	Polyamide
Lead Free	Lead Free
Length	6.99mm
Mating Alignment	With
Mating Alignment Type	Polarization
Mating Retention	With
Mating Retention Type	Locking Ramp
Max Operating Temperature	221°C
Max Voltage Rating (AC)	250v
max. cross section	0.40mm²
Max. temperature	+105°C
Min Operating Temperature	-67°C
Min. cross section	0.30mm²
Min. temperature	-55°C
Misc Attribute	MTA-100
Mount	Free Hanging, Cable, Surface Mount
Nominal Current	5A
Nominal current - rounded value	5A
Nominal Voltage	250V AC
Number of Contacts	12
Number of Positions	12
Number of Rows	1
Operating Temperature Range	-67 – 221
Operating Voltage	250
Orientation	Right Angle
Package Quantity	500
Packaging	Bag
Packaging Method	Bag/Box
Packaging Quantity	500
PCB Mount Alignment	No (Without)
PCB Mount Retention	Without
Pin shape	Rectangular
Pins per row	12
Plating Thickness	5.08um
Primary Product colour	Red
Radiation Hardening	No
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Sealable	No
Series	MTA-100
Shielded	No
Shrouded	No (Without)
Strain Relief	Yes (With)
Termination	IDC
Termination Method to Wire & Cable	Insulation Displacement (IDC)
Type	SIL socket (standard)
UL Flammability Rating	UL 94V-2
UL Rating	Recognized
Underplate Material	Nickel
Voltage Rating (AC)	250v
Width	30.48mm
Wire Size	22
Wire/Cable Gauge	22AWG
Wire/Cable Type	Discrete, Ribbon
