TE Connectivity 4-640427-0 MTA-156 Socket SIL 10 Pins 1 pc

TE Connectivity 4-640427-0 MTA-156 Socket SIL 10 Pins 1 pc

TE Connectivity
Order Code:

07-4570

Brand: TE Connectivity MPN: 4-640427-0 EAN-13: 2050002850354

Discontinued


The TE Connectivity SIL socket (standard) MTA-156 offers 10 pins for secure electrical connections. This part is suitable for connecting wires to boards, ensuring reliable and efficient performance in various electronic applications. Typical applications include use in household appliances and industrial equipment for easy assembly and maintenance.
No. of Rows 1
No. of Ways 10
Contact Finish Copper alloy
AWG (min.) 20
AWG max. 20
Board contact surface Tin plated
Case Material Polyamide
Connection Cut & Clip
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, right angle
Dim (L x W x H) 9.02 x 39.62 x 18.42 mm
Factory colour Yellow
Height 18.42mm
Industrial packaging No
Insulation Material Polyamide
Length 9.02mm
max. cross section 0.40mm²
Max. temperature +105°C
Min. cross section 0.50mm²
Min. temperature -55°C
Misc Attribute MTA-156
Nominal Current 7A
Nominal current - rounded value 7A
Nominal Voltage 600V AC
Pin shape Rectangular
Pins per row 10
Series MTA-156
Type SIL socket (standard)
Width 39.62mm
