TE Connectivity 350783-1 Universal-MATE-N-LOK Socket Housing 12 Pins

The TE Connectivity Universal-MATE-N-LOK is a socket housing cable with 12 pins. It is designed for secure electrical interconnections and supports various applications, including automotive and consumer electronics. This component is part number 350783-1 and offers reliable performance for multiple electrical systems.

Type	Socket housing cable
Pitch	6.35mm
Number of Ways	12
Number of Rows	3
Mounting Type	Panel Mount
Mounting Direction	Straight
Approvals	CSA
AWG (min.)	16
AWG max.	30
Case Material	Polyamide
Circuit Application	Power & Signal
Color	Natural, Beige, White
Colour	Ecru
Compatible With Agency/Standards Products	VDE
Compatible With Approved Standards Products	UL E28476
Connector & Contact Terminates To	Wire & Cable
Connector & Housing Type	Cap
Connector Product Type	Housing
Connector System	wire-to-wire
Connector Type	Socket, built-in
Contact Gender	Female
Contact Layout	Matrix
Contact Material	Bronze
Contact Retention	No (Without)
Contact Retention Within Housing	Without
Contact Type	Pin
Current Rating	19a
Depth	27.43mm
Dimensions	(L x W x H) 20.32 x 27.43 x 26.67 mm
ELV	Compliant
Flammability Rating	UL94 V-0
Gender	Receptacle
Glow Wire Rating	Standard Part - Not Glow Wire
Height	26.67mm
Housing Color	White
Housing Material	Nylon
Industrial packaging	No
Insulation Material	Polyamide
Length	20.32mm
Material	Nylon
Max Current Rating	19a
Max Operating Temperature	221°C
Max Voltage Rating (AC)	600v
Max Voltage Rating (DC)	600.6kV
Max. temperature	+125°C
Min Operating Temperature	-67°C
Min. temperature	-55°C
Misc Attribute	UNIVERSAL MATE-N-LOK
Mount	Panel
Nominal Current	15A
Nominal current - rounded value	15A
Nominal current (details)	15A
Nominal Voltage	600V AC
Number of Circuits	12
Number of Contacts	12
Number of Positions	12
Operating Temperature Range	-67 – 221
Operating Voltage	600
Orientation	Straight
Package Quantity	1
Packaging	Bulk
Packaging Method	Package
Packaging Quantity	1
Panel Mount Feature	With
Panel Mount Feature Type	Patch & Tabs
Panel Thickness	2.29mm
Pin shape	Circular
Pins per row	4
Primary Product colour	Natural
Reach SVHC Compliant	No
RoHS Compliant	Yes
Row Spacing	0.25mm
Row-to-Row Spacing	.25
Sealable	No
Series	Universal-MATE-N-LOK
Temperature Range	-55 - +120°C
Termination	Crimp
Termination Method to Wire & Cable	Crimp
UL Flammability Rating	UL 94V-0
UL Rating	Recognized
VDE Tested	Yes
Voltage Rating	600v
Width	27.43mm
Wire Gauge (Max)	30AWG
Wire Gauge (Min)	10AWG
