TE Connectivity 3-643816-3 MTA-100 SIL Socket 3 Pins Standard

TE Connectivity manufactures the MTA-100 SIL socket with a three-pin configuration, model number 3-643816-3. This compact and reliable socket is used primarily for quick and easy wire-to-board connections in electronics. Typical applications include connecting internal wiring in consumer electronics and computer equipment.

Pitch	2.54mm
No. of Rows	1
No. of Ways	3
Approvals	CSA
AWG (min.)	28
AWG max.	28
Backwall/Post Interruptions	No (Without)
Board contact surface	Tin plated
Body Material	Nylon
Case Material	Polyamide
Color	Green
Connection	Cut & Clip
Connector contact surface	Tin plated
Connector System	wire-to-wire
Connector Type	Socket, right angle
Contact Current Rating	5a
Contact Finish	Copper alloy
Contact Gender	Female
Contact Material	Copper Alloy
Contact Plating	Tin, Matte
Contact Retention	Yes (With)
Contact Type	Female Socket
Current Rating	5a
Depth	6.99mm
Dim	(L x W x H) 6.99 x 13.21 x 7.62 mm
Factory colour	Green
Flammability Rating	UL94 V-2
Gender	Receptacle
Height	7.62mm
Housing Color	White
Industrial packaging	No
Insulation Diameter	1.52mm
Insulation Material	Polyamide
Length	6.99mm
Mating Alignment	Yes (With)
Mating Retention	Yes (With)
Max Voltage Rating (AC)	250v
max. cross section	0.09mm²
Maximum Operating Temperature	221°C
Maximum Temperature	+105°C
Min. cross section	0.08mm²
Min. temperature	-55°C
Minimum Operating Temperature	-67°C
Misc Attribute	MTA-100
Mount	Free Hanging, Cable
Nominal Current	5A
Nominal current - rounded value	5A
Nominal Voltage	250V AC
Number of Contacts	3
Number of Positions	3
Number of Rows	1
Orientation	Right Angle
Package Quantity	500
Packaging	Box
PCB Mount Alignment	No (Without)
PCB Mount Retention	Without
Pin shape	Rectangular
Pins per row	3
Plating Thickness	5.08um
Radiation Hardening	No
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Sealable	No (Without)
Series	MTA-100
Strain Relief	Yes (With)
Termination	IDC
Type	SIL socket (standard)
Underplate Material	Nickel
Voltage Rating	250v
Voltage Rating (AC)	250v
Width	13.21mm
Wire/Cable Gauge	28AWG
Wire/Cable Type	Discrete, Ribbon
