TE Connectivity's 3-640440-8 is a female unshrouded connector with 8 contacts arranged in a single row.
The connector is designed for robust electrical performance and reliable connectivity.
Its versatility makes it suitable for use in consumer electronics and industrial equipment.
Durability and precision make it ideal for high-density applications.
| No. of Rows |
1 |
| No. of Ways |
8 |
| AWG (min.) |
22 |
| AWG max. |
22 |
| Board contact surface |
Tin plated |
| Case Material |
Polyamide |
| Centerline (Pitch) |
2.54mm |
| Circuit Application |
Signal |
| Compatible With Agency/Standards Products |
CSA |
| Compatible With Approved Standards Products |
UL E28476 |
| Connection |
Cut & Clip |
| Connector & Contact Terminates To |
Wire & Cable |
| Connector & Housing Type |
Receptacle |
| Connector contact surface |
Tin plated |
| Connector Height |
.52 |
| Connector Length |
.8 |
| Connector Mounting Type |
Cable Mount (Free-Hanging) |
| Connector Product Type |
Connector Assembly |
| Connector System |
wire-to-wire |
| Connector Type |
Socket, right angle |
| Connector Width |
.275 |
| Contact Current Rating (Max) |
5 |
| Contact Finish |
Copper alloy |
| Contact Mating Area Plating Material |
Tin (Sn) |
| Contact Retention Within Housing |
With |
| Contact Type |
Receptacle |
| Contact Underplating Material |
Nickel |
| Contacts Preloaded |
Yes |
| Dim |
(L x W x H) 6.99 x 20.32 x 13.21 mm |
| Factory colour |
Red |
| Height |
13.21mm |
| Housing Material |
Nylon |
| Industrial packaging |
No |
| Insulation Material |
Polyamide |
| Length |
6.99mm |
| Mating Alignment |
Without |
| Mating Retention |
With |
| Mating Retention Type |
Locking Ramp |
| max. cross section |
0.40mm² |
| Max. temperature |
+105°C |
| Min. cross section |
0.30mm² |
| Min. temperature |
-55°C |
| Misc Attribute |
MTA-100 |
| Nominal Current |
5A |
| Nominal current - rounded value |
5A |
| Nominal Voltage |
250V AC |
| Number of Positions |
8 |
| Number of Rows |
1 |
| Operating Temperature Range |
-67 – 221 |
| Operating Voltage |
250 |
| Packaging Method |
Bag/Box |
| Packaging Quantity |
500 |
| Pin shape |
Rectangular |
| Pins per row |
8 |
| Primary Product Color |
Red |
| Sealable |
No |
| Series |
MTA-100 |
| Shielded |
No |
| Termination Method to Wire & Cable |
Insulation Displacement (IDC) |
| Type |
SIL socket (standard) |
| UL Flammability Rating |
UL 94V-2 |
| UL Rating |
Recognized |
| Width |
20.32mm |
| Wire Size |
22 |
