TE Connectivity 3-640440-6 MTA-100 SIL Socket 6 Pins Standard

TE Connectivity 3-640440-6 MTA-100 SIL Socket 6 Pins Standard

TE Connectivity
Order Code:

07-4466

Brand: TE Connectivity MPN: 3-640440-6 EAN-13: 2050002840645

Discontinued


The TE Connectivity MTA-100 SIL socket, part number 3-640440-6, features a total of six pins and is part of the standard series. It is primarily used for connecting wires in a single in-line layout, providing reliable electrical contacts. Typical applications include use in consumer electronics, automotive systems, and telecommunications equipment, where compact and efficient connection solutions are required.
No. of Rows 1
No. of Ways 6
Contact Finish Copper alloy
AWG (min.) 22
AWG max. 22
Board contact surface Tin plated
Case Material Polyamide
Connection Cut & Clip
Connector contact surface Tin plated
Connector system wire-to-wire
Connector Type Socket, right angle
Dim (L x W x H) 6.99 x 15.24 x 13.21 mm
Factory colour Red
Height 13.21mm
Industrial packaging No
Insulation Material Polyamide
Length 6.99mm
max. cross section 0.40mm²
Max. temperature +105°C
Min. cross section 0.30mm²
Min. temperature -55°C
Misc Attribute MTA-100
Nominal Current 5A
Nominal current - rounded value 5A
Nominal Voltage 250V AC
Pin shape Rectangular
Pins per row 6
Series MTA-100
Type SIL socket (standard)
Width 15.24mm
