The TE Connectivity J-P-T pin housing cable, model 282192-1, features 4 pins with a 5 mm contact spacing, and comes as a single piece. This product is manufactured by Tyco Electronics and is known for its reliable performance in electrical connections. Typical applications include automotive, industrial equipment, and other electronic systems requiring secure and precise connections.
| Type |
Pin housing cable |
| Pitch |
5mm |
| Number of Rows |
1 |
| Case Material |
Polyamide |
| Circuit Application |
Signal |
| Color |
Black |
| Connection |
Crimp |
| Connection Angle |
180° |
| Connector contact surface |
Tin plated |
| Connector System |
automotive |
| Contact Type |
Female Socket |
| CS |
5mm |
| Depth |
38.2mm |
| Dim |
(L x W x H) 35.5 x 24.5 x 38.2 mm |
| ELV |
Compliant |
| Factory colour |
Black |
| Gender |
Female |
| Height |
38.2mm |
| Housing Color |
Black |
| Hybrid Connector |
No |
| Industrial packaging |
No |
| IP Rating |
IP54K |
| Lead Free |
Not Applicable |
| Length |
35.5mm |
| Mating Tab Width |
0.118inch |
| Max Operating Temperature |
125°C |
| Max Voltage Rating (AC) |
600v |
| max. cross section |
2.5mm² |
| Max. temperature |
+125°C |
| Min Operating Temperature |
-30°C |
| Min. cross section |
0.5mm² |
| Min. temperature |
-30°C |
| Mount |
Free Hanging, Cable |
| Number of Contacts |
4 |
| Number of Positions |
4 |
| Orientation |
Straight |
| Packaging |
Bag |
| Pin shape |
Rectangular |
| Pins per row |
4 |
| Plug / Socket |
Plug, straight |
| Polarized |
Yes |
| Primary Type |
Rectangular |
| Radiation Hardening |
No |
| RoHS Compliant |
Yes |
| Sealable |
Yes (With) |
| Series |
J-P-T |
| Serviceable |
No |
| Strain Relief |
No (Without) |
| Termination |
Crimp |
| Total number of pins |
4 |
| Width |
24.5mm |
