TE Connectivity 2301826-2 D-Sub Plug HD20 9P Male Vertical Unshrouded

TE Connectivity
MPN
2301826-2
Order Code
14-6680
Country of Origin
China
Qty Unit Price (Ex VAT)
80+ £2.79
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 80
Available to back orderBack order, lead time 4 months

The TE Connectivity 2301826-2 is a D-sub plug with a high-density 20 contact arrangement and 9-pin male configuration.

It features a vertical mounting orientation and unshrouded design for ease of use in compact spaces.

This connector is commonly used in applications requiring reliable data transmission, such as computer peripherals and industrial equipment.

The robust construction ensures dependable performance in various electronic and connectivity systems.


Type D-Shaped Connectors
Plug / Socket Plug
Mounting Type Board Mount
No. of Ways 9
Mounting Direction Vertical
Plating Material Tin
Centerline (Pitch) 2.7686mm
Circuit Application Signal
Connector & Contact Terminates To Printed Circuit Board
Connector Profile High
Connector System Wire-to-Board
Contact Current Rating (Max) 1.5
Contact Gender MALE
Contact Shape & Form Round
Housing Material PBT GF
Insulator Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Mating Retention With
Mating Retention Type 4-40 Screwlock
Number of Rows 2
Operating Temperature Range -67 – 221
Packaging Method Box & Tray
PCB Mount Retention With
PCB Mount Retention Type Boardlock
Primary Product colour Black
Row-to-Row Spacing .111
Termination Method to PCB Through Hole - Solder
Termination Type SOLDER
Total Number of Contacts 9
UL Flammability Code 94V-0
