TE Connectivity 205206-3 AMPLIMITE HD-20 D-Sub Pin Strip 180° 15 Pins

TE Connectivity produces the AMPLIMITE HD-20 (HDP-20) D-SUB pin strip. This 15-pin connector, part number 205206-3, is designed for 180-degree orientation and is typically used in data communication applications. It is often utilised in computer interfaces and industrial equipment due to its reliability and robustness.

Type	D-SUB pin strip
Plug / Socket	Plug, vertical mount
Mounting Type	Panel Mount
No. of Ways	15
Mounting Direction	180 Degree
Connection Angle	180°
Plating Material	Tin
Approvals	UL, CSA
Body Material	Steel
Centerline (Pitch)	2.7432mm
Circuit Application	Signal
Colour	Black
Connector & Contact Terminates To	Wire & Cable
Connector System	Cable-to-Cable
Contact Type	Signal
DC Rated Voltage	250v
Depth	17.7mm
Dielectric Material	Nylon
ELV	Compliant
Flammability Rating	UL94 V-0
Gender	Male
Length	39.14mm
Material	Metal
Material (details)	Housing: zinc-plated steel
Mating Connector Lock	Yes (With)
Mating Retention	With
Mating Retention Type	Mounting Holes
Max Voltage Rating (AC)	250v
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Misc Attribute	AMPLIMITE HD-20 (HDP-20)
Mount	Free Hanging, Cable
No. of Rows	2
Number of Contacts	15
Number of pins	15
Number of Positions	15
Number of Rows	2
Operating Temperature Range	-67 – 221
Orientation	Straight
Package Quantity	400
Packaging	Bulk
Packaging Method	Package
Packaging Quantity	400
Plating	Tin
Radiation Hardening	No
Reach SVHC Compliant	No
RoHS Compliant	Yes
Sealable	No
Series	AMPLIMITE HDP-20
Shell Material	Steel
Shell Size	2
Shielded	Yes
Shielding	Shielded
Termination	Crimp
Termination Method to Wire & Cable	Crimp
UL Flammability Rating	UL 94V-0
Voltage Rating (AC)	250v
Width	12.54mm
