TE Connectivity 2-215911-6 MKII Headers Female 26P Grey Unshrouded

TE Connectivity
Order Code:

14-3867

Brand: TE Connectivity MPN: 2-215911-6
Qty Unit Price (Ex VAT)
84+ £2.18
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 84
471 in stock, despatched in 5 working days

The TE Connectivity 2-215911-6 is a female MKII header with 26 positions.

It is unshrouded and comes in grey colour.

This connector is typically used in telecommunications and data communication equipment.

It provides reliable connections in a compact form factor.


Type Ribbon Cable Connectors
Pitch 2.54mm
Number of Ways 26
Number of Rows 2
Mounting Type Cable Mount (Free-Hanging)
Circuit Application Signal
Connector & Contact Terminates To Wire & Cable
Connector & Housing Type Receptacle
Connector Product Type Connector Assembly
Connector System Wire-to-Board
Contact Current Rating (Max) 1
Contact Finish Termination Tin (Sn)
Contact Gender FEMALE
Contact Mating Area Plating Material Gold (Au)
Contact Mating Area Plating Material Thickness 8
Insulator Color GRAY
Insulator Material THERMOPLASTIC
Mating Alignment Type Dual Polarizing Bar
Mating Contact Row Spacing 0.1
Mating Retention Without
Mating Square Post Dimension .025
Max Operating Temperature 105
Min Operating Temperature -20
Operating Temperature Range -85 – 221
Plating Thickness 8u
Primary Product colour Black
Reliability COMMERCIAL
Row-to-Row Spacing .1
Termination Method to Wire & Cable Insulation Displacement (IDC)
Termination Type IDC
Total Number of Contacts 26
UL Flammability Code 94V-0
