TE Connectivity's 2-179958-6 is a power connector featuring six female contacts.
This shrouded connector ensures safe and secure connections by reducing the risk of accidental disconnection.
It is typically used in industrial and commercial equipment for reliable power transmission.
The robust design and durable materials make it suitable for various demanding applications.
| Type |
Socket housing cable |
| Pitch |
10.1346mm |
| Number of Ways |
6 |
| Number of Rows |
1 |
| Mounting Type |
Cable Mount (Free-Hanging) |
| Approvals |
UL |
| Case Material |
Polyester |
| Circuit Application |
Power |
| Code |
Y |
| Color |
Black |
| Colour |
Black |
| Connector & Contact Terminates To |
Wire & Cable |
| Connector & Housing Type |
Receptacle |
| Connector contact surface |
Tin plated |
| Connector Product Type |
Housing |
| Connector System |
wire-to-board |
| Connector Type |
Socket, straight |
| Contact Type |
Female Socket |
| Depth |
29mm |
| Dimensions |
(L x W x H) 9.8 x 74 x 29 mm |
| ELV |
Compliant |
| Flammability Rating |
UL94 V-0 |
| Gender |
Female |
| Halogen free |
Halogen Free |
| Height |
29mm |
| Housing Color |
Black |
| Industrial packaging |
No |
| Insulation Material |
Polyester |
| Lead Free |
Lead Free |
| Length |
9.8mm |
| Mating Retention |
With |
| Max Operating Temperature |
221°C |
| Max Voltage Rating (AC) |
630v |
| Max. temperature |
+105°C |
| Min Operating Temperature |
-67°C |
| Min. temperature |
-55°C |
| Misc Attribute |
D-5200S |
| Mount |
Free Hanging, Cable |
| Number of Contacts |
6 |
| Number of Positions |
6 |
| Operating Temperature Range |
-67 – 221 |
| Orientation |
Straight |
| Package Quantity |
70 |
| Packaging |
Bag |
| Pin shape |
Rectangular |
| Pins per row |
6 |
| Preloaded |
No |
| Primary Product colour |
Black |
| RoHS Compliant |
Yes |
| Sealable |
No |
| Selectively Loaded |
No (Without) |
| Series |
DYNAMIC 5000 Series |
| Termination |
Crimp |
| Termination Method to Wire & Cable |
Crimp |
| VDE Tested |
No |
| Width |
74mm |
| Wire Gauge (Max) |
16AWG |
| Wire Gauge (Min) |
10AWG |
| Wire/Cable Gauge |
16AWG |
