The TE Connectivity 2-178128-3 is a wire housing designed for shrouded female connectors.
It features a 1x03 configuration, providing secure connectivity for three contact positions.
This component is typically used in electronic devices and applications requiring reliable wire-to-board connections.
The durable plastic construction ensures longevity and performance in various environments.
| Type |
Socket housing cable |
| Number of Ways |
3 |
| Number of Rows |
1 |
| Case Material |
Polyester |
| Centerline (Pitch) |
5.08mm |
| Circuit Application |
Power & Signal |
| Code |
Y |
| Colour |
Black |
| Connector & Contact Terminates To |
Wire & Cable |
| Connector & Housing Type |
Receptacle |
| Connector contact surface |
Tin plated |
| Connector Height |
.28 |
| Connector Length |
1.16 |
| Connector Mounting Type |
Cable Mount (Free-Hanging) |
| Connector Product Type |
Housing |
| Connector System |
wire-to-board |
| Connector Type |
Socket, straight |
| Connector Width |
.89 |
| Contact Base Material |
Copper Alloy |
| Contact Type |
Receptacle |
| Dimensions |
(L x W x H) 7.15 x 29.7 x 22.8 mm |
| Height |
22.8mm |
| Housing Material |
Polyester GF |
| Industrial packaging |
No |
| Insulation Material |
Polyester |
| Length |
7.15mm |
| Mating Retention |
With |
| Max. temperature |
+105°C |
| Min. temperature |
-55°C |
| Misc Attribute |
D-3200S |
| Number of Positions |
3 |
| Operating Temperature Range |
-67 – 221 |
| Packaging Method |
Bag |
| Packaging Quantity |
3200 |
| Pin shape |
Rectangular |
| Pins per row |
3 |
| Primary Product Color |
Black |
| Sealable |
No |
| Series |
DYNAMIC 3000 Series |
| Termination Method to Wire & Cable |
Crimp |
| UL Flammability Rating |
UL 94V-0 |
| Width |
29.7mm |
