TE Connectivity 166679-1 Headers DIN II 26-22AWG Male Shrouded

TE Connectivity
Order Code:

14-4088

Brand: TE Connectivity MPN: 166679-1
Qty Unit Price (Ex VAT)
250+ £0.813
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 250
Available to back orderBack order, lead time 14 days

TE Connectivity 166679-1 is a male shrouded header designed for use with DIN connectors.

It supports wire sizes from 26 to 22 AWG and offers reliable connectivity in electronics.

The part is frequently applied in telecommunications and industrial equipment.

Its durable construction ensures stability and performance in various environments.


Type Crimp Contact
Circuit Application Power & Signal
Contact Base Material Phosphor Bronze
Contact Current Rating (Max) 3
Contact Gender Male
Contact Material Bronze
Contact Mating Area Plating Material Gold (Au)
Contact Plating Gold
Contact Retention Within Housing With
Contact Type Pin
Contact Underplating Material Nickel
Gender Male
Insulation Diameter 1.6mm
Make First / Break Last No
Mating Tab Thickness .025
Mating Tab Width .026
Mount Cable
Operating Temperature Range -40 – 185
Orientation Straight
Package Quantity 200
Packaging Loose Piece
Packaging Method Box
Packaging Quantity 200
Pitch 2.54mm
Plating Thickness 0.8um
Product Terminates To Wire & Cable
Radiation Hardening No
Reach SVHC Compliant Unknown
RoHS Compliant Yes
Series AMPMODU MOD IV
Shielding Unshielded
Termination Crimp
Termination Method to Wire & Cable Crimp
Wire Gauge (Max) 26AWG
Wire Gauge (Min) 22AWG
Wire Insulation Support With
Wire Size 252.8 – 642.4
Wire/Cable Gauge 26AWG
