TE Connectivity 1658680-1 AMPLIMITE HD-22 D-SUB Pin Strip 44 Pins Crimp

The TE Connectivity AMPLIMITE HD-22 1658680-1 D-SUB pin strip has 44 pins and features a crimp connection, making it well-suited for secure and reliable data or signal transmission applications. Designed for various electronic connections, this component is particularly used in computer and industrial equipment for its robust build. It is crafted by TE Connectivity, an established manufacturer known for reliable electronic components.

Type	D-SUB pin strip
Plug / Socket	Pin strip, straight
Mounting Type	Panel Mount
No. of Ways	44
Mounting Direction	Straight
Plating Material	Tin
Approvals	UL
Body Material	Metal
Centerline (Pitch)	2.286mm
Circuit Application	Signal
Colour	Black
Compatible Insulation Diameter Range	5.51 – 11.05
Connector & Contact Terminates To	Wire & Cable
Connector System	Cable-to-Cable
Contact Type	Signal
Dielectric Material	Nylon
ELV	Compliant
Flammability Rating	UL94 V-0
Gender	Male
Housing Colour	Black
Lead Free	Not Applicable
Length	56.13mm
Material (details)	Housing material: steel · Application: Nylon
Mating Connector Lock	Yes (With)
Mating Retention	With
Mating Retention Type	Jackscrew
Max Operating Temperature	105°C
Max Voltage Rating (AC)	250v
Min Operating Temperature	-55°C
Misc Attribute	AMPLIMITE HD-22
Mount	Free Hanging
No. of Rows	3
Number of Contacts	44
Number of Positions	44
Number of Rows	3
Operating Temperature Range	-67 – 221
Orientation	Straight
Package Quantity	1
Package/Case	Metal
Packaging	Bulk
Packaging Method	Package
Packaging Quantity	1
Plating	Tin
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Sealable	No
Series	AMPLIMITE HDP-22
Shell Material	Steel
Shell Size	3
Shielded	Yes
Shielding	Shielded
Termination	Crimp
Termination Method to Wire & Cable	Crimp
UL Flammability Rating	UL 94V-0
Wire Gauge (Max)	28AWG
Wire Gauge (Min)	22AWG
Wire/Cable Diameter	0.435inch
