TE Connectivity 1-86557-9 Connector Accessory Min Cable Diameter 0.04in

Inc VAT

Qty	Unit Price (Ex VAT)
10000+	£0.219

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 10000

Available to back orderBack order, lead time 4 months

TE Connectivity 1-86557-9 is a connector accessory designed for cable management.

It accommodates a minimum cable diameter of 0.04 inches.

This product is ideal for organising and securing small-scale electronic cables.

It is commonly used in telecommunications and data networking environments.

Type	Connector Contacts
Pitch	2.54mm
Orientation	Straight
Circuit Application	Signal
Compatible Insulation Diameter Range	.04 – .056
Contact Base Material	Phosphor Bronze
Contact Current Rating (Max)	2
Contact Material	Bronze
Contact Mating Area Plating Material	Tin (Sn)
Contact Mating Area Plating Material Thickness	100
Contact Plating	Tin
Contact Type	Pin
Depth	2.33mm
Gender	Male
Height	2.03mm
Insulation Diameter	0.056inch
Length	21.1mm
Max Current Rating	3a
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-65°C
Mount	Cable
Operating Temperature Range	-85 – 221
Package Quantity	10000
Packaging	Tape and Reel
Packaging Method	Reel
PCB Contact Termination Area Plating Material	Tin
Product Terminates To	Wire & Cable
Radiation Hardening	No
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Termination	IDC
Termination Method to Wire & Cable	Insulation Displacement (IDC)
Wire Gauge (Max)	26AWG
Wire Gauge (Min)	22AWG
Wire Size	26 – 22
Wire/Cable Gauge	26AWG
Wire/Cable Type	Round, Discrete
