TDK B84112BB120 EMI filter flame retardant 250V AC 20A 1.8mH 84x125x38.1mm

TDK B84112BB120 is that serves as an EMI filter with flame retardant properties, designed to operate at 250V AC with a current rating of 20A. This EMI filter, alternatively described as 501575, features an inductance value of 1.8mH and measures 84x125x38.1mm. It is engineered to reduce electromagnetic interference in electrical systems, making it ideal for applications such as industrial automation, telecommunications infrastructure, and consumer electronics where noise reduction and compliance with emission standards are critical. The TDK B84112BB120's construction ensures reliable performance in demanding environments, adhering to rigorous safety and performance standards essential for modern engineering solutions.

Type	Flame-retardant moulded casing UL 94 V-0
Connection	Type C CEE 7/16 plug 6.3 mm
Content	1
Dimensions	(L x W x H) 84 x 125 x 38.1 mm
Height	38.1mm
Inductance (L)	1.8mH
Leakage Current	0.5mA
Length	84mm
Mounting Type	Structure
Nominal Current	20A
Nominal current - rounded value	20A
Nominal current (details)	20A
Nominal Voltage	250V AC
Nominal voltage (details)	115/250 V, 50/60 Hz
Product Type	EMI filter
Width	125mm
