Stäubli 233020-28 Safety jack socket grey Ø4 mm insulated 1 pc

Staubli
Order Code:

00-0307

Brand: Staubli MPN: 23.3020-28 EAN-13: 2050000576799
Qty Unit Price (Ex VAT)
1+ £4.26
10+ £3.96
25+ £3.64
50+ £3.29
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack order, lead time 5 weeks

Insulated, rigid 4mm socket connector with gold-plated contacts, suitable for accepting spring-loaded 4mm plugs with rigid insulating sleeve. Panel mount by fitting into cutouts in plates or housings.
Type Socket, built-in
Contact Plating Gold plated
Colour Grey
Cable Diameter 14.5mm
Connection Threaded bolts M4 or soldered hole
Dim (Ø x L) 14.5 mm x 38.5 mm
Insulation Material Insulated
Length 38.5mm
Nominal Current 32A
Nominal current - rounded value 32A
Nominal Voltage 1000V
Width 4mm
