Signal Construct SFEU087225 LED Indicator Green 12V 10320mcd

Signal Construct
Standard range
Order Code:

07-1033

Brand: Signal Construct MPN: SFEU087225
Qty Unit Price (Ex VAT)
1+ £4.85
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
43 in stock, despatched in 4 working days

Manufactured by Signal Construct, the SFEU087225 is a green LED indicator light with a high brightness of 10320 millicandela. Designed for dual voltage input, it operates on both 12 V AC and 12 V DC. Typically used in control panels, switchboards, and various signalling applications, this LED pilot light ensures clear and efficient status indication.
Type LED indicator light
Case colour Black
Connection Type C CEE 7/16 plug 2.8 mm
Energy efficiency rating n.rel.
Factory colour Green
Front panel thickness 7mm
Head height 0.80mm
IP rating IP67 (front)
Length 38.04mm
Lifespan 60000h
Light intensity I(V) 10320mcd
Material Brass
Material properties chrome plated
Max. temperature +75°C
Min. temperature -30°C
Misc Attribute 087225 SFEU
Mounting Type Screw and union
Operating current 15mA
Radiation angle 160°
Recess diameter 8mm
RoHS-compliant Yes
