The Siemens 6GK5108-0BA00-2AC2 is an industrial Ethernet switch that supports 10/100 Mbit/s speeds. It is designed to facilitate efficient network connections and data exchange in industrial environments. Commonly used in manufacturing and automation settings, it serves as a reliable LAN splitter to integrate multiple devices into a network.
| Type |
Industrial Ethernet switch |
| 10/100 Mbps ports |
8 |
| Compatible with Grade2TV according to XP-C 90-483 |
N/A |
| Compatible with Grade3TV according to XP-C 90-483 |
N/A |
| Degree of protection (IP) |
IP20 |
| Depth |
125mm |
| Ethernet |
TRUE |
| Height |
147mm |
| Interfaces |
RJ45 |
| IP Rating |
IP20 |
| Layer 2 |
TRUE |
| Layer 3 |
FALSE |
| MAC addresses |
2048 |
| Manageable |
FALSE |
| Max. ambient temperature |
+70°C |
| Max. PoE power |
N/A |
| Max. power consumption |
N/A |
| Min. ambient temperature |
-40°C |
| Misc Attribute |
6GK5108-0BA00-2AC2 |
| Mounting method |
DIN rail (top hat rail) |
| Number of combination-ports RJ45/Mini GBIC |
0 |
| Number of max. stackable switches |
0 |
| Number of module slots |
0 |
| Number of other ports |
0 |
| Number of ports 10 Gbps Mini GBIC |
0 |
| Number of ports 10 Gbps RJ45 |
0 |
| Number of ports 10/100 Mbps M12 |
0 |
| Number of ports 10/100 Mbps RJ45 |
8 |
| Number of ports 10/100/1000 Mbps RJ45 |
0 |
| Number of ports 100 Gbps Mini GBIC |
0 |
| Number of ports 100 Mbps POF |
0 |
| Number of ports 100 Mbps SC |
N/A |
| Number of ports 100 Mbps ST |
N/A |
| Number of ports 100/1000 Mbps Mini GBIC |
0 |
| Number of ports 1000 Mbps GBIC |
0 |
| Number of ports 1000 Mbps Mini GBIC |
0 |
| Number of ports 1000 Mbps POF |
N/A |
| Number of ports 1000 Mbps RJ45 |
0 |
| Number of ports 1000 Mbps SC (LX) |
0 |
| Number of ports 1000 Mbps SC (SX) |
0 |
| Number of ports 40 Gbps Mini GBIC |
0 |
| Number of ports PoE |
N/A |
| Operating Voltage |
31.2V |
| Power over Ethernet (PoE) |
N/A |
| Redundant power supply |
N/A |
| Transfer Rate |
10 / 100 MBit/s |
| Weight |
0.85kg |
| Width |
60mm |
| Working principle |
Unmanaged switch |
