Schneider Electric LP1K0910BD3 TeSys Contactor 1-phase 1pc

The Schneider Electric LP1K0910BD3 contactor is a compact electrical device used primarily for switching and controlling power circuits. It features robust construction and reliable performance, making it suitable for industrial and commercial applications. Typical uses include motor control and automation systems.

Type	Contactor
Coil Voltage	24V DC
Connection	Screw terminal
Contact Current Rating	9A
Contact Type	1 maker
Depth	57mm
Dimensions	(W x H x D) 45 x 58 x 57 mm
Height	58mm
IP Rating	IP2X
Maximum Temperature	+50°C
Min. temperature	-25°C
Mounting Style	DIN rail
Number of auxiliary contacts as normally closed contact	0
Number of auxiliary contacts as normally open contact	1
Number of normally closed contacts as main contact	0
Number of normally open contacts as main contact	3
Operating voltage AC 50 Hz	N/A
Operating voltage AC 60 Hz	N/A
Rated control supply voltage AC 50 Hz	N/A
Rated control supply voltage AC 60 Hz	N/A
Rated control supply voltage DC	24 - 24V
Rated operation current Ie at AC-1, 400 V	20A
Rated operation current Ie at AC-3, 400 V	9A
Rated operation current Ie at AC-4, 400 V	6A
Rated operation power at AC-3, 400 V	4kW
Rated operation power at AC-4, 400 V	2.2kW
Rated operation power NEMA	N/A
Suitable for distribution board	false
Terminals	Screw terminal
Type of electrical connection of main circuit	Screw connection
Voltage type for actuating	DC
Width	45mm
