Schneider Electric LC1K0910P7 Contactor 9A 3-Pole 240V 1pc

The Schneider Electric LC1K0910P7 Contactor is a robust electrical contactor designed for reliable switching and control of electrical circuits. It features durable construction and efficient performance, suitable for both industrial and commercial applications. Common uses include motor control and automation systems.

Type	Contactor
Coil Voltage	230V AC
Connection	Screw terminal
Contact Current Rating	9A
Contact Type	1 maker
Depth	35mm
Height	58mm
IP Rating	IP2X
Mounting Style	DIN rail
Number of auxiliary contacts as normally closed contact	0
Number of auxiliary contacts as normally open contact	1
Number of normally closed contacts as main contact	0
Number of normally open contacts as main contact	3
Number of Poles	3
Operating voltage AC 50 Hz	440 - 440V
Operating voltage AC 60 Hz	440 - 440V
Rated control supply voltage AC 50 Hz	230 - 230V
Rated control supply voltage AC 60 Hz	230 - 230V
Rated control supply voltage DC	N/A
Rated operation current Ie at AC-1, 400 V	20A
Rated operation current Ie at AC-3, 400 V	9A
Rated operation current Ie at AC-4, 400 V	6A
Rated operation power at AC-3, 400 V	4kW
Rated operation power at AC-4, 400 V	2.2kW
Rated operation power NEMA	N/A
Suitable for distribution board	false
Terminals	Screw terminal
Type of electrical connection of main circuit	Screw connection
Voltage type for actuating	AC
Width	45mm
