Schneider Electric GV2ME07A Overload relay 1.6-2.5A Circuit Breakers

Schneider Electric's GV2ME07A is an overload relay designed for circuit protection, offering an adjustable current range between 1.6 and 2.5 amperes. This device is engineered to integrate seamlessly with contactors, serving as a critical component in safeguarding electrical circuits from overload conditions by interrupting excessive currents. It is particularly suitable for use in motor control applications, where maintaining the operational integrity and safety of electrical systems is essential. The GV2ME07A is commonly utilised in industrial environments, providing reliable protection for motors and other electrical equipment that operate within the specified current range. Its robust design ensures consistent performance in a variety of challenging conditions, highlighting its suitability for demanding electrical engineering applications.

Type	GV2ME07A
Adjustment range (amperage)	1.6 - 2.5 A
Adjustment range undelayed short-circuit release	33.5-33.5A
Amperage adjustment range (max.)	2.5A
Amperage adjustment range (min.)	1.6A
Colour	Multicolour
Connection	Snap-in
Content	1
Depth	78.5mm
Device construction	Complete device in housing
Dimensions	(W x H x D) 45 x 101 x 78.5 mm
Height	101mm
IP Protection	IP20
IP Rating	IP20
No. of pins	3-pin
Number of Poles	3
Overload release current setting	1.6-2.5A
Phase failure sensitive	TRUE
Power loss	2.5W
Product Type	Overload relay
Rated operating voltage	230-690V
Rated operation power at AC-3, 230 V	0.37kW
Rated operation power at AC-3, 400 V	0.75kW
Rated permanent current Iu	2.5A
Rated short-circuit breaking capacity Icu at 400 V, AC	100kA
Switch off technique	Thermomagnetic
Type of control element	Push button
Type of electrical connection of main circuit	Other
Width	45mm
With integrated auxiliary switch	FALSE
With integrated under voltage release	FALSE
With thermal overload protection	TRUE
