PTR Hartmann 51700100021D Socket Housing Cable 10 Pins 3.81mm Contact Spacing

The PTR Hartmann socket housing cable features 10 pins with a contact spacing of 3.81 mm. Model number AK(Z)1700, it is ideal for connecting circuits in various electronic applications. This component is suitable for precise and reliable connections in industrial and commercial settings.

Type	Socket housing cable
Number of Positions	10
Pitch	3.81mm
Number of Rows	10
AWG (min.)	28
AWG max.	16
Case Material	PA 6.6
Colour	Green
Contact Plating	Tin plated
Cross Section	1.50mm²
Dimensions	(L x W x H) 10.40 x 38.10 x 19.10 mm
Height	19.10mm
Industrial packaging	No
Length	10.40mm
Maximum Temperature	+105°C
Min. cross section	0.14mm²
Min. temperature	-30°C
Nominal Current	8A
Nominal Voltage	300V
Series	AK(Z)1700
Stripping length (max.)	7.00mm
Width	38.10mm
