PTR Hartmann 51700040001F AK(Z)1700 Socket Housing 4 Pins 3.50mm Spacing 1pc

Image Representative of Range

PTR Hartmann 51700040001F AK(Z)1700 Socket Housing 4 Pins 3.50mm Spacing 1pc

PTR
Order Code:

06-2890

Brand: PTR MPN: 51700040001F EAN-13: 2050001582867
Qty Unit Price (Ex VAT)
5+ £0.954
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
9 in stock, despatched in 4 working days

The PTR Hartmann socket housing cable features a total of 4 pins with a contact spacing of 3.50 mm. It is suitable for applications requiring reliable electrical connections and compact design. Its model number is 51700040001F and can be used in both industrial and commercial electronic assemblies.
Type Socket housing cable
Number of Positions 4
Number of Rows 4
Contact Plating Tin plated
AWG (min.) 28
AWG max. 16
Case Material PA 6.6
Colour Green
Cross Section 1.50mm²
Dimensions (L x W x H) 10.40 x 19.10 x 14.00 mm
Height 14.00mm
Industrial packaging No
Length 10.40mm
Max. temperature +105°C
Min. cross section 0.14mm²
Min. temperature -30°C
Nominal Current 8A
Nominal Voltage 300V
Series AK(Z)1700
Stripping length (max.) 7.00mm
Width 19.10mm
