PTR Hartmann 51100080001D Hartmann Socket 8 Pins 5.08mm Housing Cable AK(Z)1100

PTR Hartmann manufactures the socket housing cable AK(Z)1100 with a total of 8 pins and a contact spacing of 5.08 mm. This component, identified by part number 51100080001D, is typically used for secure electrical connections in various electronic devices. It is suitable for applications requiring reliable pin contact spacing and durable housing.

Type	Socket housing cable
Number of Positions	8
Pitch	5.08mm
Number of Rows	8
AWG (min.)	22
AWG max.	10
Case Material	PA 6.6
Colour	Green
Contact Plating	Tin plated
Cross Section	4.00mm²
Dimensions	(L x W x H) 12.50 x 40.64 x 26.50 mm
Height	26.50mm
Industrial packaging	No
Length	12.50mm
Maximum Temperature	+105°C
Min. cross section	0.20mm²
Min. temperature	-30°C
Nominal Current	15A
Nominal Voltage	300V
Series	AK(Z)1100
Stripping length (max.)	7.00mm
Width	40.64mm
