PTR Hartmann 51100050021E AK(Z)1100 Socket Housing Cable 5 Pins 5mm Spacing

PTR Hartmann produces the AK1100 socket housing cable, featuring 5 pins and a contact spacing of 5 mm. This versatile connector, identified as part number 51100050021E, is ideal for secure and efficient electrical connections. Common applications include electronic devices demanding reliable power and signal transmission.

Type	Socket housing cable
Number of Positions	5
Pitch	5mm
Number of Rows	5
AWG (min.)	22
AWG max.	10
Case Material	PA 6.6
Colour	Green
Contact Plating	Tin plated
Cross Section	4.00mm²
Dimensions	(L x W x H) 12.50 x 26.50 x 25.00 mm
Height	25.00mm
Industrial packaging	No
Length	12.50mm
Maximum Temperature	+105°C
Min. cross section	0.20mm²
Min. temperature	-30°C
Nominal Current	15A
Nominal Voltage	300V
Series	AK(Z)1100
Stripping length (max.)	7.00mm
Width	26.50mm
