PTR Hartmann 51100030021F Hartmann Socket Housing 3 Pins 5mm Spacing 1pc

Image Representative of Range

PTR Hartmann 51100030021F Hartmann Socket Housing 3 Pins 5mm Spacing 1pc

PTR
Extended range
Order Code:

06-2858

Brand: PTR MPN: 51100030021F
Qty Unit Price (Ex VAT)
1+ £0.696
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack order, lead time 6 weeks

PTR Hartmann manufactures the socket housing cable AK1100 with 3 pins and a contact spacing of 5 mm. It is identified by part number 51100030021F and typically used in electrical and electronic connections for reliable performance. The product is suitable for applications that require secure and precise connections.
Type Socket housing cable
AWG (min.) 22
AWG max. 10
Case material PA 6.6
Connector contact surface Tin plated
Connector system wire-to-board
Connector type Socket, straight
Contact material Copper alloy
CS 5mm
Dim (L x W x H) 12.50 x 26.50 x 15.00 mm
Factory colour Green
Height 15.00mm
Industrial packaging No
Length 12.50mm
Manufacturer part # 51100030021F
max. cross section 4.00mm²
Max. temperature +105°C
Min. cross section 0.20mm²
Min. temperature -30°C
Misc Attribute AK1100/3-5.0-GRÜN
No. of rows 1
Nominal current 15A
Nominal current - rounded value 15A
Nominal voltage 300V
Pins per row 3
RoHS-compliant Yes
Series AK(Z)1100
Stripping length (max.) 7.00mm
Total number of pins 3
Width 26.50mm
