PTR Hartmann 50950107028D Socket Housing 10 Pins 5.08mm Spacing

Image Representative of Range

PTR Hartmann 50950107028D Socket Housing 10 Pins 5.08mm Spacing

PTR
Order Code:

06-2844

Brand: PTR MPN: 50950107028D EAN-13: 2050001583710
Qty Unit Price (Ex VAT)
2+ £2.47
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
230 in stock, despatched in 4 working days

The PTR Hartmann AKZ950/10-5.08 is a socket housing suitable for connecting cables with its ten-pin configuration, ensuring reliable electrical connections. With a contact spacing of 5.08 mm, it is designed for precise and secure cable housing applications. Typically used in electronic and electrical installations, it offers durability and compatibility with various pin configurations.
Type Socket housing cable
Number of Positions 10
Number of Rows 10
Contact Plating Tin plated
AWG (min.) 28
AWG max. 12
Case Material PA 6.6
Colour Green
Cross Section 4.00mm²
Dimensions (L x W x H) 15.00 x 52.30 x 19.20 mm
Height 19.20mm
Industrial packaging No
Length 15.00mm
Max. temperature +105°C
Min. cross section 0.20mm²
Min. temperature -30°C
Nominal Current 10A
Nominal Voltage 300V
Series AK(Z)950
Stripping length (max.) 7.00mm
Width 52.30mm
