PTR Hartmann 50950087028D AK(Z)950 Socket Housing 8 Pins 5.08mm Spacing

Image Representative of Range

PTR Hartmann 50950087028D AK(Z)950 Socket Housing 8 Pins 5.08mm Spacing

PTR
Standard range
Order Code:

06-2843

Brand: PTR MPN: 50950087028D
Qty Unit Price (Ex VAT)
1+ £1.97
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
183 in stock, despatched in 4 working days

The PTR Hartmann socket housing cable, model AKZ950/8-5.08, features 8 pins with a contact spacing of 5.08 mm. Designed for secure and reliable electrical connections, it is ideal for use in various electronic and industrial applications. This high-quality component ensures optimal performance and durability in complex circuitry setups.
Type Socket housing cable
AWG (min.) 28
AWG max. 12
Case material PA 6.6
Connector contact surface Tin plated
Connector system wire-to-board
Connector type Socket, straight
Contact material Copper alloy
CS 5.08mm
Dim (L x W x H) 15.00 x 42.14 x 19.20 mm
Factory colour Green
Height 19.20mm
Industrial packaging No
Length 15.00mm
Manufacturer part # 50950087028D
max. cross section 4.00mm²
Max. temperature +105°C
Min. cross section 0.20mm²
Min. temperature -30°C
Misc Attribute AKZ950/8-5.08
No. of rows 1
Nominal current 10A
Nominal current - rounded value 10A
Nominal voltage 300V
Pins per row 8
RoHS-compliant Yes
Series AK(Z)950
Stripping length (max.) 7.00mm
Total number of pins 8
Width 42.14mm
