PTR 54951120421D AK(Z)4951 Socket Housing 12 Pins 5.08 mm Spacing

PTR
Order Code:

12-8083

Brand: PTR MPN: 54951120421D EAN-13: 2050001584083
Qty Unit Price (Ex VAT)
2+ £2.08
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
8 in stock, despatched in 4 working days

PTR Hartmann manufactures the socket housing cable AKZ4951/12KD-5.08 with 12 pins and a contact spacing of 5.08 mm. This socket housing is typically used for secure electrical connections in electronic equipment and control systems. The part number for this product is 54951120421D and it is usually sold individually.
Type Socket housing cable
AWG (min.) 26
AWG max. 12
Case Material PA 6.6
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Copper alloy
CS 5.08mm
Depth 25.60mm
Dim (W x H x D) 60.96 x 15.00 x 25.60 mm
Factory colour Basalt grey
Height 15.00mm
Industrial packaging No
max. cross section 2.50mm²
Max. temperature +105°C
Min. cross section 0.14mm²
Min. temperature -30°C
Misc Attribute AKZ4951/12KD-5.08
Nominal Current 10A
Nominal current - rounded value 10A
Nominal Voltage 300V
Number of Rows 1
Pins per row 12
Series AK(Z)4951
Stripping length (max.) 12.00mm
Total number of pins 12
Width 60.96mm
