PTR 54951100401D Socket Housing Cable 10 Pins, 5mm Spacing

PTR
Standard range
Order Code:

12-8082

Brand: PTR MPN: 54951100401D EAN-13: 2050001583987
Qty Unit Price (Ex VAT)
1+ £2.03
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
15 in stock, despatched in 4 working days

PTR Hartmann manufactures the AK4951/10KD-5.0 socket housing cable, a durable connector with 10 pins and 5 mm contact spacing. It is suitable for efficient organising and securing cable connections. This component is typically used in industrial and electronic applications requiring reliable multi-pin cable interfaces.
Type Socket housing cable
AWG (min.) 26
AWG max. 12
Case material PA 6.6
Connector contact surface Tin plated
Connector system wire-to-board
Connector type Socket, straight
Contact material Copper alloy
CS 5mm
Depth 25.60mm
Dim (W x H x D) 50.00 x 15.00 x 25.60 mm
Factory colour Basalt grey
Height 15.00mm
Industrial packaging No
Manufacturer part # 54951100401D
max. cross section 2.50mm²
Max. temperature +105°C
Min. cross section 0.14mm²
Min. temperature -30°C
Misc Attribute AK4951/10KD-5.0
No. of rows 1
Nominal current 10A
Nominal current - rounded value 10A
Nominal voltage 300V
Pins per row 10
RoHS-compliant Yes
Series AK(Z)4951
Stripping length (max.) 12.00mm
Total number of pins 10
Width 50.00mm
