PTR 54951050401D AK(Z)4951 Socket Housing 5 Pins 5 mm Spacing

PTR
Standard range
Order Code:

12-8080

Brand: PTR MPN: 54951050401D EAN-13: 2050001583949
Qty Unit Price (Ex VAT)
1+ £1.15
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
82 in stock, despatched in 4 working days

PTR Hartmann's socket housing cable model AK4951/5KD-5.0 features five pins with a contact spacing of 5 mm. This component, with part number 54951050401D, is ideal for secure electrical connections in cable assemblies. It is commonly used in electronic and electrical applications requiring reliable pin configuration.
Type Socket housing cable
AWG (min.) 26
AWG max. 12
Case material PA 6.6
Connector contact surface Tin plated
Connector system wire-to-board
Connector type Socket, straight
Contact material Copper alloy
CS 5mm
Depth 25.60mm
Dim (W x H x D) 25.00 x 15.00 x 25.60 mm
Factory colour Basalt grey
Height 15.00mm
Industrial packaging No
Manufacturer part # 54951050401D
max. cross section 2.50mm²
Max. temperature +105°C
Min. cross section 0.14mm²
Min. temperature -30°C
Misc Attribute AK4951/5KD-5.0
No. of rows 1
Nominal current 10A
Nominal current - rounded value 10A
Nominal voltage 300V
Pins per row 5
RoHS-compliant Yes
Series AK(Z)4951
Stripping length (max.) 12.00mm
Total number of pins 5
Width 25.00mm
