PTR 54951040421D Socket Housing 4 Pins 5.08mm Spacing

PTR
Standard range
Order Code:

12-8079

Brand: PTR MPN: 54951040421D EAN-13: 2050001584021
Qty Unit Price (Ex VAT)
1+ £0.870
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
4 in stock, despatched in 4 working days

PTR Hartmann socket housing cable, model AKZ4951/4KD-5.08, features a total of 4 pins with a contact spacing of 5.08 mm. This component, identified by part number 54951040421D, is suitable for secure electrical connections in various electronic assemblies. Typical applications include use in industrial electronics and control systems.
Type Socket housing cable
AWG (min.) 26
AWG max. 12
Case material PA 6.6
Connector contact surface Tin plated
Connector system wire-to-board
Connector type Socket, straight
Contact material Copper alloy
CS 5.08mm
Depth 25.60mm
Dim (W x H x D) 20.32 x 15.00 x 25.60 mm
Factory colour Basalt grey
Height 15.00mm
Industrial packaging No
max. cross section 2.50mm²
Max. temperature +105°C
Min. cross section 0.14mm²
Min. temperature -30°C
Misc Attribute AKZ4951/4KD-5.08
No. of rows 1
Nominal current 10A
Nominal current - rounded value 10A
Nominal voltage 300V
Pins per row 4
RoHS-compliant Yes
Series AK(Z)4951
Stripping length (max.) 12.00mm
Total number of pins 4
Width 20.32mm
