PTR 54951040401D Hartmann Socket Housing 4 Pins 5mm Spacing

PTR
Order Code:

12-8078

Brand: PTR MPN: 54951040401D EAN-13: 2050001583932
Qty Unit Price (Ex VAT)
5+ £0.929
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
220 in stock, despatched in 4 working days

PTR Hartmann manufactures the AK4951/4KD-5.0 socket housing cable, featuring 4 pins with a contact spacing of 5 mm. This component is typically used in electronic connections where reliable wiring is essential. Ideal for custom electrical setups and installations, it is available as a single unit with part number 54951040401D.
Type Socket housing cable
Number of Ways 4
Number of Rows 1
Colour Basalt grey
AWG (min.) 26
AWG max. 12
Case Material PA 6.6
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Copper alloy
CS 5mm
Depth 25.60mm
Dimensions (W x H x D) 20.00 x 15.00 x 25.60 mm
Height 15.00mm
Industrial packaging No
max. cross section 2.50mm²
Max. temperature +105°C
Min. cross section 0.14mm²
Min. temperature -30°C
Misc Attribute AK4951/4KD-5.0
Nominal Current 10A
Nominal current - rounded value 10A
Nominal Voltage 300V
Pins per row 4
Series AK(Z)4951
Stripping length (max.) 12.00mm
Width 20.00mm
