PTR 54951020401D AK(Z)4951 Socket Housing 2 Pins 5mm Spacing

PTR
Order Code:

12-8075

Brand: PTR MPN: 54951020401D EAN-13: 2050001583918
Qty Unit Price (Ex VAT)
10+ £0.455
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
197 in stock, despatched in 4 working days

PTR Hartmann manufactures the socket housing cable AK4951/2KD-5.0, which features two pins with a contact spacing of 5 mm. This component is typically used in electrical connections for secure and reliable transmission. It is often found in applications requiring precise pin alignment, such as industrial machinery or electronic devices.
Type Socket housing cable
AWG (min.) 26
AWG max. 12
Case Material PA 6.6
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Copper alloy
CS 5mm
Depth 25.60mm
Dim (W x H x D) 10.00 x 15.00 x 25.60 mm
Factory colour Basalt grey
Height 15.00mm
Industrial packaging No
max. cross section 2.50mm²
Max. temperature +105°C
Min. cross section 0.14mm²
Min. temperature -30°C
Misc Attribute AK4951/2KD-5.0
Nominal Current 10A
Nominal current - rounded value 10A
Nominal Voltage 300V
Number of Rows 1
Pins per row 2
Series AK(Z)4951
Stripping length (max.) 12.00mm
Total number of pins 2
Width 10.00mm
