PTR 50950035651F STLZ950 Pin Housing 3 Pins 5.08mm Pitch PCB Mount

PTR
Standard range
Order Code:

12-8065

Brand: PTR MPN: 50950035651F EAN-13: 2050001584106
Qty Unit Price (Ex VAT)
1+ £0.218
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
121 in stock, despatched in 4 working days

The PTR Hartmann pin housing PCB STLZ950 has three pins with a contact spacing of 5.08 mm. It is ideal for connecting circuit boards in various electronic projects and applications. Manufactured by PTR Hartmann, this component offers reliable connections and is suitable for use in both domestic and industrial electronics.
Type Pin housing PCB
Board contact surface Tin plated
Case material PA 6.6
Connection Print
Connector contact surface Tin plated
Connector system wire-to-board
Connector type Plug, vertical mount
Contact material Copper alloy
CS 5.08mm
Factory colour Basalt grey
Industrial packaging No
Max. temperature +105°C
Min. temperature -30°C
Misc Attribute STL950/3G-5.0-V
No. of rows 1
Nominal current 10A
Nominal current - rounded value 10A
Nominal voltage 300V
Pins per row 3
RoHS-compliant Yes
Series STLZ950
Total number of pins 3
Width 16.2mm
