PTR 50950035611F STLZ950 PCB Pin Housing 3 Pins 5.08mm Spacing

PTR
Standard range
Order Code:

12-8064

Brand: PTR MPN: 50950035611F EAN-13: 2050001584199
Qty Unit Price (Ex VAT)
1+ £0.238
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
238 in stock, despatched in 4 working days

The PTR Hartmann pin housing PCB STLZ950 features a total of three pins with a 5.08 mm contact spacing. Manufactured by PTR Hartmann, this component is known for its precision and reliability in electrical connections. It is typically used in circuit board assemblies for electronic devices, providing secure and efficient pin housing.
Type Pin housing PCB
Board contact surface Tin plated
Case material PA 6.6
Connection Print
Connector contact surface Tin plated
Connector system wire-to-board
Connector type Plug, vertical mount
Contact material Copper alloy
CS 5.08mm
Factory colour Basalt grey
Industrial packaging No
Max. temperature +105°C
Min. temperature -30°C
Misc Attribute STLZ950/3G-5.08-V
No. of rows 1
Nominal current 10A
Nominal current - rounded value 10A
Nominal voltage 300V
Pins per row 3
RoHS-compliant Yes
Series STLZ950
Total number of pins 3
Width 16.4mm
