Potentiometer Service RV16AF-10-15R1-B1K Slide Potentiometer Linear 1k Ohm

Potentiometer Service RV16AF-10-15R1-B1K is a slide potentiometer with a resistance of 1k ohm, classified under the type RV16AF-10-15R1-9302/B1K. This variable resistor is engineered with precision to provide linear resistance adjustments, making it suitable for controlling voltage, tuning, and adjusting signals in electronic circuits. Typically used in applications such as audio equipment, lighting control, and instrumentation, the RV16AF-10-15R1-B1K offers consistent performance and reliability. Its slide operation allows for easy adjustment and integration into various design layouts, ensuring versatile usage across multiple engineering domains.

Type	Single turn rotary pot
Resistance	1kO
Tolerance	± 20%
Power Rating	0.125W
Taper	linear
Lever Length	15mm
Axle Diameter	6.35mm
Connection	Solder tag
Content	1
Maximum Temperature	+70°C
Mechanical Angle	300°
Minimum Temperature	-10°C
Output	Mono
Thread Size	M7
Tolerance ±	20%
