Potentiometer RV16AF-10-15R_B5K-3 Slide Potentiometer 5K Ohm 16mm Length

Potentiometer Service RV16AF-10-15R_B5K-3 is a slide potentiometer designed with a resistance value of 5 kilohms and a precise track length of 16 millimetres. This variable resistor, identifiable by its manufacturer's part number, RV16AF-10-15R_B5K, provides smooth linear control of electrical signals and is ideal for applications requiring fine-tuned voltage adjustment. Commonly utilised in audio mixing consoles, adjustable power supplies, and various instrumentation control devices, the potentiometer offers reliable performance across a range of environments. Its compact design and robust construction make it suitable for professional engineering purposes, ensuring accurate and lasting operation in both dynamic and static settings.

Type	Single turn rotary pot
Resistance	5kΩ
Tolerance	± 20%
Power Rating	0.125W
Taper	linear
Lever Length	15
Axle Diameter	6.35mm
Connection	Wire
Content	1
Maximum Temperature	70°C
Mechanical Angle	300°
Minimum Temperature	10°C
Output	Mono
Thread Size	M7
Tolerance ±	5%
