Phoenix Contact 1912812 Printed-circuit board connector - MVSTBW 2,5 HC/10-ST - PCB connector, nominal cross section: 2.5 mm2, colour: green, nominal current: 16 A (see derating curve), rated voltage (III/2): 320 V, contact surface: Sn, contact connection type: Socket, number of potentials: 10, number of rows: 1, number of positions: 10, number of connections: 10, product range:
MVSTBW 2,5 HC/..-ST, pitch: 5 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, conductor/PCB connection direction: -90 °, locking clip: - Locking clip, plug-in system:
COMBICON MSTB 2,5 HC, locking: without, mounting: without, type of packaging: packed in cardboard.
- Nominal current IN: 16 A (see derating curve)
- Nominal voltage UN: 320 V
- Rated voltage: 250 V
- Rated surge voltage: 4 kV
- Rated voltage: 320 V
- Rated surge voltage: 4 kV
- Rated voltage: 630 V
- Rated surge voltage: 4 kV
| Number of Positions |
10 |
| Angle contact/conductor connection |
Other |
| Coating housing |
N/A |
| Connectable cable type |
Tubular cable |
| Connectable conductor cross section fine-strand with cable end sleeve |
0.25 - 2.5mm² |
| Connectable conductor cross section fine-strand without cable end sleeve |
0.2 - 2.5mm² |
| Connectable conductor cross section multi-wired |
- - -mm² |
| Connectable conductor cross section solid-core |
0.2 - 2.5mm² |
| Contact Finish |
Tin |
| Contact Type |
Bus |
| Degree of protection (IP), mounted |
N/A |
| Housing Colour |
Green |
| Housing Material |
Other |
| Inflammability class of insulation material according to UL94 |
V0 |
| Material contact |
Copper |
| Material insulation body |
Polyamide (PA) |
| Material of contact surface |
Tin |
| Modular spacing connections |
5mm |
| Modular spacing contacts |
5mm |
| Mounting Type |
PCB |
| Number of plug-in contact rows |
1 |
| Number of Poles |
10 |
| Number of Rows |
1 |
| Operating Temperature |
-40 - 100°C |
| Overvoltage category |
III |
| Pitch |
5mm |
| Pollution degree |
2 |
| Rated current In |
16A |
| Rated Surge Voltage |
4kV |
| Rated voltage |
320V |
| Type of connection |
Other |
| Type of electric connection |
Screw connection |
| With protective conductor |
N/A |
