Phoenix Contact 1815264 PTSM Pin housing 2 pins 2.50 mm spacing

The Phoenix Contact pin housing PCB, model number 1815264, is a multi-pin connector with a total of 2 pins and a contact spacing of 2.50 mm. This component is typically used in circuit board applications, providing reliable electrical connection for various electronic projects. Its compact design makes it suitable for use in space-constrained environments.

Type	Pin housing PCB
Number of Positions	2
Number of Rows	1
Angle PCB/contact	N/A
Colour	White
Connection	Print
Connector model	Other
Connector orientation	Perpendicular (to the PCB)
Connector System	wire-to-board
Connector Type	Plug, vertical mount
Contact Material	Tin plated
Contact Type	Pin
Cross Section	2.50mm
Diameter connection pin	1.1mm
Dimensions	(L x W x H) 5.00 x 9.50 x 6.70 mm
Height	6.70mm
Housing Colour	Other
Industrial packaging	No
Inflammability class of insulation material according to UL94	V0
Length	5.00mm
Length pin	2mm
Material insulation body	Other
Material of contact surface	Other
Misc Attribute	PTSM 0,5/ 2-HV-2,5-THR WH R32
Modular spacing connections	2.5mm
Modular spacing contacts	2.5mm
Nominal Current	6A
Nominal Voltage	50V
Number of plug-in contact rows	1
Number of Poles	2
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pins per row	2
Pollution degree	2
Rated current In	6A
Rated Surge Voltage	2.5kV
Rated voltage	160V
Series	PTSM
Suitable for PCB thickness	N/Amm
Type of banding	Other
Type of connection	N/A
Type of electric connection	Other
Type of fastening	Other
Type of PCB fastening	N/A
Width	9.50mm
