Phoenix Contact 1814906 PTSM Pin housing PCB 8 pins 2.50mm spacing

Phoenix Contact's pin housing PCB PTSM features a total of 8 pins with a contact spacing of 2.50 mm. This multi-pin connector is typically used in electronic and printed circuit board applications to facilitate secure and precise electrical connections. It is ideal for environments requiring reliable conductivity and compact design.

Type	Pin housing PCB
Number of Positions	8
Number of Rows	1
Angle PCB/contact	N/A
Colour	White
Connection	Print
Connector model	Other
Connector orientation	Parallel (to the PCB)
Connector System	wire-to-board
Connector Type	Plug, vertical mount
Contact Material	Tin plated
Contact Type	Pin
Cross Section	2.50mm
Diameter connection pin	1.1mm
Dimensions	(L x W x H) 7.10 x 21.70 x 7.50 mm
Height	7.50mm
Housing Colour	Other
Industrial packaging	No
Inflammability class of insulation material according to UL94	V0
Length	7.10mm
Length pin	2.1mm
Material insulation body	Other
Material of contact surface	Other
Misc Attribute	PTSM 0,5/ 8-HH-2,5-THR WH R44
Modular spacing connections	2.5mm
Modular spacing contacts	2.5mm
Nominal Current	6A
Nominal Voltage	50V
Number of plug-in contact rows	1
Number of Poles	8
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pins per row	8
Pollution degree	2
Rated current In	6A
Rated Surge Voltage	2.5kV
Rated voltage	160V
Series	PTSM
Suitable for PCB thickness	N/Amm
Type of banding	Other
Type of connection	N/A
Type of electric connection	Other
Type of fastening	Other
Type of PCB fastening	N/A
Width	21.70mm
