Phoenix Contact offers a pin housing PCB with a total of 2 pins and a contact spacing of 2.50 mm. This component is well-suited for multi-pin connector applications in electronic and electrical systems. Typical applications include use in printed circuit boards where secure and reliable connections are required.
| Type |
Pin housing PCB |
| Number of Positions |
2 |
| Number of Rows |
1 |
| Angle PCB/contact |
N/A |
| Colour |
White |
| Connection |
Print |
| Connector model |
Other |
| Connector orientation |
Parallel (to the PCB) |
| Connector System |
wire-to-board |
| Connector Type |
Plug, vertical mount |
| Contact Material |
Tin plated |
| Contact Type |
Pin |
| Cross Section |
2.50mm |
| Diameter connection pin |
1.1mm |
| Dimensions |
(L x W x H) 6.70 x 7.50 x 7.10 mm |
| Height |
7.10mm |
| Housing Colour |
Other |
| Industrial packaging |
No |
| Inflammability class of insulation material according to UL94 |
V0 |
| Length |
6.70mm |
| Length pin |
2.1mm |
| Material insulation body |
Other |
| Material of contact surface |
Other |
| Misc Attribute |
PTSM 0,5/ 2-HH-2,5-THR WH R16 |
| Modular spacing connections |
2.5mm |
| Modular spacing contacts |
2.5mm |
| Nominal Current |
6A |
| Nominal Voltage |
50V |
| Number of plug-in contact rows |
1 |
| Number of Poles |
2 |
| Operating Temperature |
-40 - 100°C |
| Overvoltage category |
III |
| Pins per row |
2 |
| Pollution degree |
2 |
| Rated current In |
6A |
| Rated Surge Voltage |
2.5kV |
| Rated voltage |
160V |
| Series |
PTSM |
| Suitable for PCB thickness |
N/Amm |
| Type of banding |
N/A |
| Type of connection |
N/A |
| Type of electric connection |
Other |
| Type of fastening |
Other |
| Type of PCB fastening |
N/A |
| Width |
7.50mm |
