Molex 675820000 Crimp Housing 15-pin 1.27mm Pitch Serial Ata Black

The Molex 675820000 is a socket housing cable with 15 pins designed for precise electronic connections. Manufactured by Molex, it features a contact spacing of 1.27 mm for compact and efficient wiring solutions. This part is typically used in consumer electronics and telecommunications equipment.

Type	Socket housing cable
Pitch	1.27mm
Number of Ways	15
Number of Rows	1
Mounting Type	Cable mount
Mounting Direction	Straight
Application	Power, Wire-to-Board
Base unit of measure	PC
Base unit of measure desc	piece
Case Material	Polyester
China ro h s status	Compliant per SJ/T 11365-2006
Circuits detail	5 sets terminal per housing
Circuits maximum	15
Color resin	Black
Colour	Black
Connector Type	Socket
CS	1.27mm
Delivery unit	7000
Design registration eligibility	true
ELV status	Compliant per 2000/53/EC
Engineering number	67582-0000
Engineering Part No	67582-0000
Engineering Series Name	Power cable rcpt hsg
Engineering Series No	67582
First published date	2008-06-24
G a d s l/ i m d s	Not Relevant
Gender	Receptacle
Glow wire capable	No
H f l h status	Not Low-Halogen per IEC 61249-2-21
Keying to mating part	Yes
Lock to mating part	No
Material resin	Polyester
Material type	Semi-finished product
Max. temperature	+85°C
Min. temperature	-35°C
Minimum line quantity	14000
Misc Attribute	Molex MOL DataCom & Specialty
Net weight	2.160/g
Packaging Type	Bag
Panel mount	No
Pitch termination interface	1.27mm
Polarized to mating part	No
Ports	1
Primary pack qty	500
Product name	Serial ATA
Product number display	675820000
Product number hyphen	67582-0000
Product number sap	0675820000
Reach status	Not Contained per D(2025)7771-DC (04 Feb 2026)
Reference series	67582
Ro h s status	Compliant per EU 2015/863
Sampleable	True
Stackable	No
Taxonomy	Connector Housings
Temperature range operating	-35° to +85°C
Ul	E29179
Upc	800756591391
