The Molex socket housing cable, model number 50375043, features 4 pins with a contact spacing of 2.5 mm. Manufactured by Molex, this component is typically used in electronic assemblies requiring secure and precise cable connections. It is ideal for various applications in both consumer electronics and industrial equipment.
| Type |
Socket housing cable |
| Pitch |
2.5mm |
| Number of Ways |
4 |
| Number of Rows |
1 |
| Mounting Type |
Cable mount |
| Mounting Direction |
Straight |
| Application |
Signal, Wire-to-Board |
| Base unit of measure |
PC |
| Base unit of measure desc |
piece |
| Case Material |
Nylon (NL) |
| China ro h s status |
Compliant per SJ/T 11365-2006 |
| Circuits maximum |
4 |
| Color resin |
Natural |
| Colour |
Ecru |
| Connector System |
wire-to-board |
| Connector Type |
Socket |
| CS |
2.5mm |
| Design registration eligibility |
false |
| ELV status |
Not Relevant |
| Engineering number |
5264-04 |
| Engineering Part No |
5264-04 |
| Engineering Series Name |
Rcpt Hsg |
| Engineering Series No |
05264 |
| First published date |
2007-05-16 |
| Flammability |
94V-0 |
| G a d s l/ i m d s |
Not Relevant |
| Gender |
Receptacle |
| Glow wire capable |
No |
| H f l h status |
Low-Halogen per IEC 61249-2-21 |
| Lock to mating part |
Yes |
| Material resin |
Nylon |
| Material type |
Finished Goods |
| Maximum Temperature |
+105°C |
| Min. temperature |
-40°C |
| Misc Attribute |
Molex MOL Power & Signal Sol. |
| Net weight |
224.900/mg |
| Packaging Type |
Bag |
| Panel mount |
No |
| Polarized to mating part |
Yes |
| Product name |
Mini-SPOX |
| Product number display |
50375043 |
| Product number hyphen |
50-37-5043 |
| Product number sap |
0050375043 |
| Reach status |
Not Contained per D(2025)7771-DC (04 Feb 2026) |
| Reference series |
5264 |
| Ro h s status |
Compliant per EU 2015/863 |
| Sampleable |
True |
| Stackable |
No |
| Taxonomy |
Connector Housings |
| Temperature range operating |
-55° to +105°C |
| Ul |
E29179 |
| Upc |
800753578364 |
