Molex 5013300200 Pico-clasp Socket 2-pin 1mm Pitch White 1Pc Bag

Molex
Order Code:

05-3801

Brand: Molex MPN: 5013300200 EAN-13: 2050007115717
Qty Unit Price (Ex VAT)
20+ £0.227
250+ £0.187
1000+ £0.166
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
1,398 in stock, despatched in 4 working days

The Molex socket housing cable, model 5013300200, features a total of 2 pins with a contact spacing of 1 mm. It is typically used in applications requiring compact and reliable electrical connections. This part is ideal for electronic projects or devices that require efficient and small-scale wiring solutions.
Type Socket housing cable
Pitch 1.00mm
Number of Ways 2
Number of Rows 1
Application Signal, Wire-to-Board
Base unit of measure PC
Base unit of measure desc piece
Case Material Nylon (NL)
China ro h s status Compliant per SJ/T 11365-2006
Circuits maximum 2
Color resin White
Colour White
Connector System wire-to-board
Connector Type Socket
CS 1mm
Delivery unit 80000
Design registration eligibility true
Elv status Not Relevant
Engineering number 501330-0200
Engineering Part No 501330-0200
Engineering Series Name SGL Rcpt Hsg Inner
Engineering Series No 501330
First published date 2007-05-16
Flammability 94V-0
G a d s l/ i m d s Not Relevant
Gender Receptacle
Glow wire capable No
H f l h status Low-Halogen per IEC 61249-2-21
Keying to mating part No
Lock to mating part Yes
Material resin Nylon
Material type Finished Goods
Max. temperature +105°C
Min. temperature -40°C
Minimum line quantity 80000
Misc Attribute Molex MOL Power & Signal Sol.
Net weight 20.800/mg
Packaging Type Bag
Panel mount No
Pitch termination interface 1.00mm
Polarized to mating part Yes
Primary pack qty 1000
Product name Pico-Clasp
Product number display 5013300200
Product number hyphen 501330-0200
Product number sap 5013300200
Reach status Not Contained per D(2025)7771-DC (04 Feb 2026)
Reference series 501330
Ro h s status Compliant per EU 2015/863
Sampleable True
Stackable No
Taxonomy Connector Housings
Temperature range operating -40° to +105°C
Ul E29179
Upc 822348528998
